Servo Control Automatic Corrugated Carton Box Making Machine Labor Saving

  • 1
  • 2

Brand Name : Toprint

Model Number : TP-CR-0920/1224-FFG,

Certification : CE Certificate, Patent Certificate

Place of Origin : Guangdong,CN

MOQ : 1 set

Price : Negotiation

Payment Terms : L/C, T/T

Supply Ability : 3 Sets per Month

Delivery Time : 45-65 days

Packaging Details : Steel Base with Carton and Film Wrapping

Name : Servo Control High Folding Accuracy Cardboard Carton Box Making Machine Flexo Folder Gluer Automatic Strapping Machine

Type : For Make Corrugated Cartons

Voltage : 380V 50HZ Or Custom

Condition : Brand New

Service : Engineers Available To Service Machinery Overseas, Video Technical Support, Field Installation, Online Support, Commissioning And Training

Warranty : 1 Years After Installation

Automatic Type : Full Automatic, High Speed

Loading Port : Guangzhou Of China

Color : Custom

Contact Now

Servo Control High Folding Accuracy Cardboard Carton Box Making Machine Flexo Folder Gluer Automatic Strapping Machine Full Set for Make All kind of Cartons High Efficiency

SUMMARY OF MACHINE

  1. Cardboard Box Making Machine, also called one-step cardboard box production line, is designed to process corrugated cardboard into products such as cartons, boxes, trays, displays etc.
  2. It can finish the process of Pre-feeding, feeding, printing, pre-creasing, creasing, slotting, die-cutting, gluing, counting and strapping at one time.
  3. The standard model of Cardboard Box Making Machine includes TP-CR-0920/1224-FFG, also the 0922/1228/1424/1632 be custom-made.

The Q6 featured with the functions as below marked by “√”.

1st Process 2nd Process 3rd Process 4th Process 5th Process
Order setting Pre feeding Feeding 1-6 color Printing Slotting
√ √ √ √ √

6th Process 7th Process 8th Process 9th Process 10th Process
Die cutting Creasing Gluing Counting Strapping
√ √ √ √ √

Specification

Servo Control Automatic Corrugated Carton Box Making Machine Labor Saving

Model TP-CR-0920 TP-CR-1224 TP-CR-1628
Size 0920 1224 1628
Max.Sheet Size (FxA) 890x2000 1190x2400 1600x2800
Skip Feed Size (FxA) 1200x2000 1400x2400 1800x2800
Min.Sheet Size (FxA) 280x700 350x720 450x850
Max.Printing Area (FxA) 890x1960 1190x2360 1600x2760
Top Speed(Sheet/min) 300 250 180
Economic Speed (sheet/min) 150-250 120-220 100-160
Min. Slotting Space-Reverse Knife (BxCxBxC) 270x100x270x100 270x100x270x100 320x120x320x120
Min. Slotting Space-Normal Knife (BxCxBxC) 160x160x160x160 160x160x160x160 160x160x160x160
Max. Slot Depth Size 250 320 450
Min. Box Height Size 110 110 160
Max. Die-Cutting Area 850x1950 1150x2350 1530x2750
Sheet Thickness 1.5-11 1.5-11 1.5-11
Thickness of Printing Plate 7.2 7.2 7.2

SEMI-AUTOMATIC PRE-FEEDER

Servo Control Automatic Corrugated Carton Box Making Machine Labor Saving

  1. Pre-feeder is used to connect with automatic flexo printer machine.
  2. Conveyor arm length is motorized and adjusted freely.
  3. Back squarer is automatic along with conveyor.

FLEXO FOLDER GLUER

Servo Control Automatic Corrugated Carton Box Making Machine Labor Saving

Feeding Unit

  1. Lead edge feeder with vacuum absorber.
  2. Upper Dust remover with brushers
  3. Sheet transfer with rubber pull rolls.
  4. Gap of feeding rollers, Side baffles are computerized with order managing.

Printing Unit

  1. Sheet transfer with vacuum box.
  2. Anilox roller with rubber roller inking or Anilox roller with Chambered doctor blade system for choosing.
  3. Quick replacing of rubber roller.
  4. Gap of anilox roller, printing drum, vacuum box and horizontal and vertical movement are computerized with order managing.

Slotting Unit

  1. Sheet transfer with rollers.
  2. 8-shafts rotation: Pre-creasing, Dual-Creasing, Single shaft slotting.
  3. All slotting knife holders connect with creasing rings and slotting knifes, synchronously moving in horizontal position.
  4. Gaps of creasers and slotting knifes, box height, registering and vertical moving are computerized with order managing.

Die cutting Unit

  1. Sheet transfer with rollers.
  2. Upper die cutting rubber roller is driven by independent frequency converter for line speed compensation.
  3. Shaft-head treated with lock, not welding, given strong capacity of bearing pressure.
  4. Gaps of feeding, registering and vertical moving are computerized with order managing.

FFG- Folder Gluer & Counter Ejector

  1. Top loading type Counter Ejector.
  2. Rolling wheel or auto flexo gluing system for choosing.
  3. Adjustment with servo motors.
  4. Gaps of Hold-Arm, Glue head and conveyor bracket are computerized with order managing.
  5. Central computer system controls whole units of machine.

AUTOMATIC PP STRAPPING MACHINE

Servo Control Automatic Corrugated Carton Box Making Machine Labor Saving

  1. Cartons transferred by rolling wheel.
  2. Precision single piece strap track for positive control and exceptional feed reliability.
  3. Control system using ARM system.
  4. Strapping materials: PP

ADVANTAGES

  1. High capability: Maximum output up to 15000 per hours
  2. Labor saving: 3-4 workers for whole processes, to match with Auto Strapping machine.
  3. Easy Job: Order saving and quick changing by 5-10 min.
  4. Wide range application: Be used to agriculture, food, logistics and industrial packaging.
  5. Acceptability in Precision: More than 99% for printing accuracy and Up-Fold gap.
  6. Control with 9 sets of Servo Motor, Bosch Rexroth Brand origin from German.

Accuracy Assurance

Feeding ≤ ±1.5 mm
Printing(4 colors) ≤ ± 0.5 mm
Slotting ≤ ± 1.5 mm
Die-cutting ≤ ± 1.5 mm
Up-fold gap(For FFG) 3-layer ≤ ± 2 mm
5-layer ≤ ± 3 mm
“Fishtail” issue (For FFG) 3-layer ≤ ± 1.5 mm
5-layer ≤ ± 2 mm
